VCP550 Online Practice Questions and Answers

-- Exhibit -

-- Exhibit -

An administrator determines that traffic shaping does not appear to be working on Production, a virtual machine port group on vSwitch1. Traffic shaping is working on all

other port groups on the switch.

The administrator examines the Traffic Shaping settings as shown in the exhibit:

What should the administrator do to resolve the problem?

A. Select the Status checkbox to enable Traffic Shaping on the portgroup.

B. Reduce the Average Bandwidth to 50% of the Peak Bandwidth.

C. Reduce the Burst Size to 50% of the Peak Bandwidth.

D. Click the Security tab and create the necessary security exception.

A vSphere administrator can create an alarm on which two objects? (Choose two.)

A. LUN

B. Datastore

C. Template

D. Folder

A vSphere administrator creates a new vSphere Distributed Switch. The administrator receives notice from the service desk that a cluster of vSphere hosts has disconnected from vCenter Server. This disconnect occurred immediately after the new switch was created.

This vSphere Distributed Switch is the only distributed switch managed by vCenter.

The virtual machines are still functional and the applications are still accessible by end users.

On the ESXi hosts, which step must the vSphere administrator take to allow vCenter Server to reconnect?

A.

Use the Direct Console User Interface to reattach the management vmnic to the appropriate switch

B.

Use the Direct Console User Interface to disable lockdown mode on each affected host

C.

Use the ESXi Shell to restart the mgmt-vmware service on each affected host

D.

Use the ESXi Shell to restart the vSphere Web Client service on each affected host

A vSphere administrator is administering a vSphere Distributed Switch port group using the vSphere Web Client. The port group was configured using Static binding, but the number of ports must increase as virtual machines are added to the port group.

Which port allocation setting should the administrator use to achieve this goal?

A. Elastic

B. Dynamic

C. Fixed

D. Manual

Which two statements are true regarding a new vSphere deployment that is using software FCoE boot from SAN? (Choose two.)

A. Multi-pathing options must be configured by the vmkernel after boot.

B. The adapter must support iBFT or UEFI.

C. The adapter must support FBFT or FBPT.

D. Multi-pathing options must be configured in the Boot ROM.

The vSphere administrator needs to migrate a virtual machine from one host to another.

The virtual machine .vswp file resides in local storage.

Which two techniques can the administrator use to migrate the virtual machine? (Choose two.)

A. vMotion migration

B. Cold migration

C. Storage vMotion migration

D. Enhanced vMotion migration

A vSphere administrator notices that hosts are not powering off when the total cluster load is low on a cluster configured with Dynamic Power Management. What condition could cause this behavior?

A. The DRS migration threshold is set to the most conservative setting.

B. The DRS migration threshold is set to the most aggressive setting.

C. The DPM migration threshold is set to the most conservative setting.

D. The DPM migration threshold is set to the most aggressive setting..

While shutting down a vApp for maintenance, a vSphere administrator determines that one of the virtual machines stays powered on. The administrator manually powers off the virtual machine inside the vApp. Which step should the administrator take to prevent the virtual machine from staying powered on in the future?

A. Change the Shutdown Action for the virtual machine to None

B. Change the Shutdown Action for the virtual machine to Power Off

C. Change the Shutdown Action for the virtual machine to Manual

D. Change the Shutdown Action for the virtual machine to Excluded

The following error displays during the final step of the configuration for a VMware High Availability (HA) cluster attached to five datastores:

The number of heartbeat datastores for host is 0, which is less than requireD. 2

What condition would cause this error?

A. One of the hosts in the cluster is not attached to the datastores planned for use with HA.

B. The hosts in the cluster do not have Storage DRS configured on one or more of their datastores.

C. One of the hosts in the cluster has an invalid Storage Policy configured on one or more of their datastores.

D. The hosts in the cluster contain one or more datastores configured with a 1 MB block size.

Which two statements accurately describes step that are taken to recover a virtual machine using vSphere Replication? (Choose two.)

A. A recovery is initiated from the target site.

B. A recovery is initiated from the source site.

C. Upon recovery, the virtual machine is automatically attached to it's configured network.

D. Upon recovery, the virtual machine must be manually attached to a network.
