PROFESSIONAL-CLOUD-NETWORK-ENGINEER Online Practice Questions and Answers

Your company just completed the acquisition of Altostrat (a current GCP customer). Each company has a separate organization in GCP and has implemented a custom DNS solution. Each organization will retain its current domain and host names until after a full transition and architectural review is done in one year. These are the assumptions for both GCP environments.

1.

Each organization has enabled full connectivity between all of its projects by using Shared VPC.

2.

Both organizations strictly use the 10.0.0.0/8 address space for their instances, except for bastion hosts (for accessing the instances) and load balancers for serving web traffic.

3.

There are no prefix overlaps between the two organizations.

4.

Both organizations already have firewall rules that allow all inbound and outbound traffic from the 10.0.0.0/8 address space.

5.

Neither organization has Interconnects to their on-premises environment.

You want to integrate networking and DNS infrastructure of both organizations as quickly as possible and with minimal downtime.

Which two steps should you take? (Choose two.)

A. Provision Cloud Interconnect to connect both organizations together.

B. Set up some variant of DNS forwarding and zone transfers in each organization.

C. Connect VPCs in both organizations using Cloud VPN together with Cloud Router.

D. Use Cloud DNS to create A records of all VMs and resources across all projects in both organizations.

E. Create a third organization with a new host project, and attach all projects from your company and Altostrat to it using shared VPC.

You have recently been put in charge of managing identity and access management for your organization. You have several projects and want to use scripting and automation wherever possible. You want to grant the editor role to a project member.

Which two methods can you use to accomplish this? (Choose two.)

A. GetIamPolicy() via REST API

B. setIamPolicy() via REST API

C. gcloud pubsub add-iam-policy-binding Sprojectname --member user:Susername --role roles/editor

D. gcloud projects add-iam-policy-binding Sprojectname --member user:Susername --role roles/editor

E. Enter an email address in the Add members field, and select the desired role from the drop-down menu in the GCP Console.

Your company has separate Virtual Private Cloud (VPC) networks in a single region for two departments: Sales and Finance. The Sales department's VPC network already has connectivity to on-premises locations using HA VPN, and you have confirmed that the subnet ranges do not overlap. You plan to peer both VPC networks to use the same HA tunnels for on-premises connectivity, while providing internet connectivity for the Google Cloud workloads through Cloud NAT. Internet access from the on-premises locations should not flow through Google Cloud. You need to propagate all routes between the Finance department and on-premises locations. What should you do?

A. Peer the two VPCs, and use the default configuration for the Cloud Routers.

B. Peer the two VPCs, and use Cloud Router's custom route advertisements to announce the peered VPC network ranges to the on-premises locations.

C. Peer the two VPCs. Configure VPC Network Peering to export custom routes from Sales and import custom routes on Finance's VPC network. Use Cloud Router's custom route advertisements to announce a default route to the on-premises locations.

D. Peer the two VPCs. Configure VPC Network Peering to export custom routes from Sales and import custom routes on Finance's VPC network. Use Cloud Router's custom route advertisements to announce the peered VPC network ranges to the on-premises locations.

You recently deployed your application in Google Cloud. You need to verify your Google Cloud network configuration before deploying your on-premises workloads. You want to confirm that your Google Cloud network configuration allows traffic to flow from your cloud resources to your on-premises network. This validation should also analyze and diagnose potential failure points in your Google Cloud network configurations without sending any data plane test traffic. What should you do?

A. Use Network Intelligence Center's Connectivity Tests.

B. Enable Packet Mirroring on your application and send test traffic.

C. Use Network Intelligence Center's Network Topology visualizations.

D. Enable VPC Flow Logs and send test traffic.

You have the following routing design. You discover that Compute Engine instances in Subnet-2 in the asia-southeast1 region cannot communicate with compute resources on-premises. What should you do?

A. Configure a custom route advertisement on the Cloud Router.

B. Enable IP forwarding in the asia-southeast1 region.

C. Change the VPC dynamic routing mode to Global.

D. Add a second Border Gateway Protocol (BGP) session to the Cloud Router.

Your company is running out of network capacity to run a critical application in the on-premises data center. You want to migrate the application to GCP. You also want to ensure that the Security team does not lose their ability to monitor traffic to and from Compute Engine instances.

Which two products should you incorporate into the solution? (Choose two.)

A. VPC flow logs

B. Firewall logs

C. Cloud Audit logs

D. Stackdriver Trace

E. Compute Engine instance system logs

Your company runs an enterprise platform on-premises using virtual machines (VMS). Your internet customers have created tens of thousands of DNS domains panting to your public IP addresses allocated to the Vtvls Typically, your customers hard-code your IP addresses In their DNS records You are now planning to migrate the platform to Compute Engine and you want to use Bring your Own IP you want to minimize disruption to the Platform What Should you d0?

A. Create a VPC and request static external IP addresses from Google Cloud Assagn the IP addresses to the Compute Engine instances. Notify your customers of the new IP addresses so they can update their DNS

B. Verify ownership of your IP addresses. After the verification, Google Cloud advertises and provisions the IP prefix for you_ Assign the IP addresses to the Compute Engine Instances

C. Create a VPC With the same IP address range as your on-premises network Asson the IP addresses to the Compute Engine Instances.

D. Verify ownership of your IP addresses. Use live migration to import the prefix Assign the IP addresses to Compute Engine instances.

You are creating an instance group and need to create a new health check for HTTP(s) load balancing. Which two methods can you use to accomplish this? (Choose two.)

A. Create a new health check using the gcloud command line tool.

B. Create a new health check using the VPC Network section in the GCP Console.

C. Create a new health check, or select an existing one, when you complete the load balancer's backend configuration in the GCP Console.

D. Create a new legacy health check using the gcloud command line tool.

E. Create a new legacy health check using the Health checks section in the GCP Console.

You are creating a new application and require access to Cloud SQL from VPC instances without public IP addresses. Which two actions should you take? (Choose two.)

A. Activate the Service Networking API in your project.

B. Activate the Cloud Datastore API in your project.

C. Create a private connection to a service producer.

D. Create a custom static route to allow the traffic to reach the Cloud SQL API.

E. Enable Private Google Access.

You have the following private Google Kubernetes Engine (GKE) cluster deployment: You have a virtual machine (VM) deployed in the same VPC in the subnetwork kubernetes-management with internal IP address 192.168.40 2/24 and no external IP address assigned. You need to communicate with the cluster master using kubectl. What should you do?

A. Add the network 192.168.40.0/24 to the masterAuthorizedNetworksConfig. Configure kubectl to communicate with the endpoint 192.168.38.2.

B. Add the network 192.168.38.0/28 to the masterAuthorizedNetworksConfig. Configure kubectl to communicate with the endpoint 192.168.38.2

C. Add the network 192.168.36.0/24 to the masterAuthorizedNetworksConfig. Configure kubectl to communicate with the endpoint 192.168.38.2

D. Add an external IP address to the VM, and add this IP address in the masterAuthorizedNetworksConfig. Configure kubectl to communicate with the endpoint 35.224.37.17.
