You need to install a cluster with a FAS2720 HA pair and a FAS8300 HA pair.
Which NetApp tool will verify which cluster interconnect switches support this configuration?
A. Active IQ Config Advisor
B. Interoperability Matrix Tool (IMT)
C. Hardware Universe (HWU)
D. mysupport.netapp.com site
When you install a new ONTAP 9.7 4-node cluster, which network type is required?
A. data network
B. peering network
C. cluster interconnect
D. intercluster network
You are installing a new ONTAP 9.7 cluster and attaching the cluster to two separate networks. Your customer has indicated that the same range of client IP addresses are used on both networks and that the networks are never allowed to communicate with each other.
In this scenario, which ONTAP feature must be configured to securely allow all clients to access ONTAP NAS protocols?
A. BGP
B. broadcast domains
C. routing
D. IPspaces
Click the Exhibit button.
You are installing a new FAS cluster. The management network must be on tagged VLAN 11 for remote administration by a service provider.
Referring to the exhibit, which two ports will allow service provider access to both cluster and node management LIFs? (Choose two.)
A. e0M
B. e0b-11
C. e0a-11
D. e0M-11
Click the Exhibit button.
You are installing a 2-node AFF A400 switchless cluster. You have cabled the management network to the e0M port. NetApp also recommends cabling to a redundant management network switch.
Referring to the exhibit, to which port should the redundant management network be cabled?
A. 3
B. 2
C. 1
D. 4
You are installing a 4-node AFF A400 cluster and are asked to create a custom security message before and after user login.
Which two security features are used to perform this task? (Choose two.)
A. EMS
B. banner
C. motd
D. AutoSupport
In an ONTAP switched cluster, which three types of traffic travels over the cluster network? (Choose three.)
A. intercluster SnapMirror
B. intracluster SnapMirror
C. Epsilon voting
D. cluster database replication
E. remote cluster peering
You are installing a new FAS2750 cluster with 24 HDDs for a customer to run a NAS workload. The customer requests that the HA pair have only a single aggregate that is located on Node 1. Maximum capacity is required.
Which action must be performed to ensure that the customer's requests are satisfied?
A. Perform a takeover of Node 2 to ensure that it does not run.
B. Assign all data LIFs to Node 1.
C. Assign all the partitioned disks from Node 2 to Node 1, and create a single aggregate.
D. Assign all the data partitions from Node 2 to Node 1, and create a single aggregate.
Click the Exhibit button.
A customer has two Cisco 40GbE data switches. They want to connect the switches to an AFF A400 HA pair. The switches and the AFF A400 are approximately seven meters apart.
Referring to the exhibit, which two supported actions would allow you to accomplish this task? (Choose two.)
A. Relocate the switches or the AFF A400 so that the distance is less than five meters.
B. Install 10 meter NetApp supported copper cables.
C. Change the requirement for Ethernet cables.
D. Change the requirement for optical cables.
You want to verify that connections are cables correctly and that shelf IDs are unique within an HA pair. Which tool would be used to accomplish these tasks?
A. System Diagnostics
B. Cloud Insights
C. Active IQ Config Advisor
D. Active IQ Unified Manager
