HPE6-A80 Online Practice Questions and Answers

DRAG DROP

Match each hospital room with a potential issue for the AP design (Each match will be used once.)

Select and Place:

Refer to the exhibit.

The network architect has created the 60M shown in the exhibit tor a complete new wired ana wireless solution for a customer. This solution the customer wants to discover and manage every component or the network in Airwave, including twins, MCS, APS, and switches.

How many AirWave licenses dees the architect need to add?

A. 30

B. 222

C. 7122

D. 6930

An indoor basKetbaiI stadium has 5.000 seats in two rings:

The stadium has a ceiling height of GO feet (18 m).

There is a catwalk around the perimeter of the basketball court, between the court and the seating areas.

This catwalk is 40 feet (12 m) from the floor.

There are two scoreboards at either end of the stadium.

The construction of the stadium is concrete and sleet.

The customer does not want an under-seat, picoceli deployment.

Which AP model is appropriate to provide coverage in the main stadium bawl?

A. AP-577

B. AP-555

C. AP-575

D. AP-505

A company already has an Aruba wireless network The network currently consists of: * oneMM-HW-1k

*

two 7210 MCs in the network core

*

two 721GMCsintheDMZ

*

200 AP-515S in Building 1 and Building 5

100 AP-515S each In Building 2r Building 3, and Building 4

The customer now wants to assess if it needs local Mobility controllers (MC) for any buildings:

- Building 1 is the main office building for the campus. It supports the highest number of APs. It connects to the network core without an aggregation layer.

*

Building 2 is further away from the Building i. and no roaming is provided between it and the other buildings its access layer connects to the network cone with a pair of Aruba CX 6300M aggregation switches.

*

Building 3 is further away from the other buildings, it connects to the network core without an aggregation layer.

The Guest SSID traffic should be tunnelled to the DMZ controllers

' Building 4 has its own local datacenter and Internet connection. The company would like it to be able to operate completely autonomously if its aggregation layer loses connectivity with the core.

*

Building 5 is further away from the other buildings, it connects to the network core without an aggregation layer.

This building has been assigned to a partner that would like to manage a dedicated SS1D using the shared AP infrastructure.

In which two buildings should the network architect plan local mobility controllers (MCs)? (Select two)

A.

Building 1

B.

Building 4

C.

Building 5

D.

Building 3

E.

Building 2

Refer to the exhibit.

The exhibit shows the topology for a new Aruba solution. The MCs are in a ctuster and support all of the wireless traffic in

the network The core switches route all traffic and support all VLANS. The access fayer switches do NOT use tunneiednode. or dynamic segmentation.

The customer has indicated that it has these VLANS for user devices.

*

VLAN 11 for Floori employee wired devices

*

VLAN 12 for Floor 2 employee wired devices

*

VLAN 13 tor Floor 3 employee wired devices

*

VLAN 14 for Floor 4 employee wired devices

*

VLAN 15 for Floor 5 employee wired devices

*

VLAN 101 for all employee wireless devices

*

VLAN 102 for all guest wireless devices

In which locations should the architect plan the VLANs?

A.

VLANs 11-15 on one MC. VLANs 101 and 102 on the other MC. (Other VLANs will be used on the access layer switches.)

B.

VLANs 11-15. 101. and 102 on both MCs. (Other VLANs will be used on the access layer switches.)

C.

VLANs 11-15 on the access layer switches on the corresponding floor; VLAN 101 on one MC and VLAN 102 on me other MC

D.

VLANS 11-15 on the access layer switches on the corresponding floor; VLANS 101 and 102 on both MCS.

A retail customer is doing a wired and a wireless refresh with Arut>a CX switches and S02.11ax APs. Currently, trey nave wireless Point of Sales (PoS) systems and would like to assure that the proposed deployment solution will comply with the Payment Card Industry (PCI) Data Security Standard (DSS) requirements. The architect have proposed the following deployment solutions regarding PCI DSS requirements' -IDS/IPS -Aruba APs in hybrid mode as well as in dedicated AMs mode -Strong authentication and encryption for wireless -Built-in firewall and role-based access controls to segment WLAN Which other requirements must you include in the existing deployment solution? (Select two.)

A. Select the FIPS/TAA-compliant version for the Access Points.

B. Suggest MACSet between the Aruba CX switches that encrypt all traffic over the link.

C. Switch high-availability solution VSF and VSX also can encrypt all traffic on their switch links.

D. Aruba Central or Aruba AirWave to generate a scheduled compliance reporting.

E. Role-based access controls for wired users using ClearPass. Optionally ; tunneled-node to MCs.

What is one reason to deploy an Aruba CX switch when compared to an ArubaOS switch?

A. to obtain API-enabled programmability for greater automation

B. to support Aruba Dynamic Segmentation

C. to obtain higher wattage power modules for enhanced PoE+ support

D. to support Zero Touch provisioning (ZTP)

A customer has an existing; Aruba wireless solution to provide wireless access for employees. The solution Includes Aps,mobility controllers (MCs) at the network core, and a Mobility Master (MM} A customer would like to set up a separatelymanaged guest network and have the traffic go directly to the DMZ.

What should the architect suggest as the simplest solution that meets the requirements?

A. Have a dedicated mobility controller in the DMZ managed by the same MM

B. Double the number of APs and controllers.

C. Use MulitZone, and put a mobility controller in Itie DMZ.

D. Add APs in a dedicated AP group to support only the guest network SSID.

A nospltai needs an upgrade to 802.11ax for its wireless network, which needs to provide complete coverage The hospital has a concrete exterior and uses drywalls lor all of the interior walls with a few exceptions as mandated for safety The building has 10fool (3 m) ceilings. The hospital prefers to avoid the deployment of APs in rooms if possible. Exceptions include reception areas and lounges. The wireless network must support wireless medical devices, voice communicators for medical star, laptops in nursestations, medical staff tablets, and visitor and patient personal devices. All of these devices support both the 2.4GHz

and5GHz band.

The exhibits below show one wing of one floor of the hospital. This wing is about 2S.Q0D square feet {2GQQ sq, m). The unlabeled rooms along the bottom of the wing are patient rooms' other rooms such as lounges and the MR] room are

labeled. This area has:

*

up to SO concurrent patients and visitors, who might have up to two devices

*

about 200 medical and other types of wireless devices

The architect has already planned to place APs in stairwells on another floor.

Which AP plan for this wing of this floor meets the customer needs?

A.

Option A

B.

Option B

C.

Option C

D.

Option D

An indoor sports stadium has 5.000 seats in two rings:

The stadium has a ceiling height of 72 feet (22 m).

There is a catwalk around the perimeter of me stadium that is 54 feet (13 m) from me floor.

There are two scoreboards at either end of the stadium

The construction of the stadium is concrete and steel.

The customer has indicated a preference for overhead coverage, and the wireless network should support 3500 concurrent clients. The architect plans to install the APs on the catwalk to service sections of the floor below

Which type or antennas are recommended for the APS that provide the overhead coverage?

A. downtilt

B. high gain directional

C. high gain omnidirectional

D. vagi
