9L0-012 Online Practice Questions and Answers

What color indicates that the Liquid Contact Indicators inside a MacBook Pro (13-inch, Mid 2012, have been triggered?

A. Red

B. Blue

C. White

D. Yellow

You must know the AppleCare name of an Intel iMac before performing which of the following actions?

A. Starting up from OS X Recovery HD.

B. Running Mac Resource Inspector.

C. Replacing the logic board

D. Resetting the NVRAM.

Which of the following desktop Macs supports going into Safe Sleep after four hours of inactivity if the computer is using OS X v10.8.2 or newer?

A. iMac (Late 2011)

B. Mac Pro (Mid 2012)

C. Mac mini (Mid 2011)

D. Mac mini (Late 2012)

Which component for Apple Service Toolkit is designed to help troubleshoot issues with MagSafe and MagSafe 2 power adapters?

A. NAD

B. VST

C. TPT

D. CSD

Which of the following is a best practice when handling the embedded battery from MacBook Air models'?

A. Use the battery cable or connector to lift the battery.

B. Hold the battery carefully by its edges only with two hands.

C. Grasp the middle of the battery cells when removing it from the computer.

D. Re-cover any punctures or tears in the soft Mylar covering with Kapton tape

You are about to replace a MacBook Air (11-inch. Mid 2013) logic board. Which of the following is the most important step you should take immediately after removing the bottom case?

A. Remove the thermal module.

B. Install the battery cover.

C. Remove the SSD carrier

D. Remove the battery.

Examine the image. When repairing a Mac mini (Mid 2011), which areas of the logic board assembly should you avoid touching?

A. The top and bottom of the assembly.

B. The EMI fingers and gasket.

C. The grounding pad and cable guide

D. Thermal pad and heat sink clips.

What should be done to protect the Thunderbolt and USB 3 port during handling or shipment of the Mac Book Pro (Retina, 13-inch, Late 2012, Early 2013 and Late 2013 logic board?

A. Install screws on logic board.

B. Immediately place logic board into ESD bag to protect ports.

C. Install port covers over the ports

D. Use Kapton tape cover the ports and the C-shaped EMI ground tabs

You are using a television attached to the HDMI port of a MacBook Pro (Retina, 15-inch Early 2013) but cannot see the menu bar. What section of the Display pane in System Preferences would help with this issue?

A. Overscan/Underscan

B. Color Profile

C. Detect Displays

D. Gather Windows

After disconnecting all other Mac Pro (Late 2013) parts, which of the following components remains?

A. Thermal center

B. Thermal unit

C. Thermal core

D. Thermal structure
