4A0-104 Online Practice Questions and Answers

Which of the following about IES is FALSE?

A. An IES provides a Layer 3 interface to a customer.

B. A virtual routing/forwarding table is created per IES service.

C. An IES supports QoS.

D. An IES interface's IP address, if bound to a port, will appear in the routing table.

Click the exhibit.

Based on this output from PE router R1, how many other PEs are participating in the VPRN?

A. 0

B. 1

C. 2

D. 3

What needs to be configured before a SAP appears? (Choose two.)

A. Configuring the physical port in access mode.

B. Configuring the physical port in network mode.

C. Enabling the port using the no shutdown command.

D. Ports are enabled by default, thus no need to use the no shutdown command.

A customer requests that their Layer 2 Ethernet service be configured to forward frames up to 1514 bytes. The service provider is using MPLS encapsulation and RSVP-TE fast-reroute with facilities bypass on their redundant IP/MPLS network. What is the minimum MTU setting for the network ports?

A. 1514

B. 1528

C. 1536

D. 1540

E. 1560

How many SAPs can be configured on a port configured with dot1q encapsulation?

A. 1

B. 4095

C. None. This encapsulation is not supported.

D. The number is limited only by the capacity of the router

Which of the following about VPRN labels is FALSE?

A. The outer label allows traffic to transit across the MPLS network.

B. The inner label identifies the VPRN service.

C. MP-BGP is used to signal VPRN labels.

D. The VPRN service label contains the customer's IP address.

Which of the following statements are TRUE regarding sdp-ping? (Choose three.)

A. Provides a mechanism to determine the hops an SDP traverses.

B. Provides in-band uni-directional connectivity tests.

C. Provides in-band round-trip connectivity tests.

D. Tests ability of reaching the far-end IP address of an SDP ID within the SDP encapsulation.

E. Provides information regarding the exact MTU supported between service ingress and service termination.

A technician sitting in a Network Operations Center would like to set up a remote mirror on a Nokia 7750 Service Router to examine some data traffic ingressing a port at a remote site. Which of the following are required? (Choose two.)

A. A mirror destination on the local and remote Nokia Service Router.

B. A mirror source on the local and remote Nokia Service Router.

C. A mirror source with the remote source specified on the remote Nokia Service Router.

D. A mirror source with the remote source specified on the local Nokia Service Router.

E. An SDP between the local and remote Nokia Service Routers.

Click on the exhibit button below.

Is a routing policy required on PE1 to advertise a CE1's system interface to PE2?

A. Yes. A routing policy is required to advertise routes between PE routers in a VPRN

B. No. A routing policy is not required; the default behavior on the Nokia 7750 SR is to advertise all VPRN routes between PE routers.

C. A routing policy is required only when BGP is used as the PE-CE routing protocol, as shown in the exhibit.

D. A CE1 system interface can not be advertised to PE2 since the CE routers are not aware of the VPRN.

Which of the following statements best describes an FDB used in a VPLS service?

A. A VPLS service does not use an FDB.

B. An FDB is maintained on the PE router to track MAC addresses learned from all traffic through the router.

C. An FDB is maintained on the PE router to track MAC addresses learned from all VPLS services on the router.

D. A separate FDB is maintained for each VPLS service to track MAC addresses learned from each service.

E. For each VPLS service, two FDBs are maintained to track MAC addresses; one for unicast traffic and one for multicast and broadcast traffic.
