350-601 Online Practice Questions and Answers

DRAG DROP

An engineer configures the NetFlow feature on a Cisco NX-OS device. The requirement is to reduce the amount of export data collected by using a sampler. Drag and drop the NetFlow configuration steps from the left onto the implementation needed to meet these requirements on the right. Not all steps are used.

Select and Place:

DRAG DROP Refer to the exhibit.

An engineer implements a dynamically negotiated LACP port channel on SW1. The port channel members must be configured as active/standby ports with Eth1/2 as active and Eth1/1 as standby. The Eth1/1 interface is configured with default priority. Drag and drop the code snippets from the right onto the blanks in the code on the left to complete the Eth1/2 interface configuration for SW1. Not all code snippets are used.

Select and Place:

Refer to the exhibit.

Which statement about the default gateway configuration of the vPC is true?

A. N7K-1 acts as the default gateway for all traffic.

B. N7K-2 forwards traffic that is destined for the default gateway by using the peer link.

C. N7K-2 acts as the default gateway for all traffic.

D. Either switch can act as the active default gateway.

An engineer is configuring a backup operation on the existing Cisco UCS environment using a logical configuration. Which configuration is expected to be saved by using this backup type?

A. systems

B. roles

C. service profiles

D. servers

An engineer is seeking the most optimal on demand CPU performance while configuring the BIOS settings of UCS C-series rack mount server.

A. C0/C1 state

B. C6 Retention

C. C2 state

D. C6 non-Retention

What are two capabilities of the Cisco Network Assurance Engine? (Choose two.)

A. It verifies the speed of network packet flows by using telemetry.

B. It predicts the network load on a data center.

C. It validates that devices comply with network security policies.

D. It ensures that network performance meets an SLA.

E. It predicts the impact of changes to the network.

A network engineer plans to upgrade the firmware of a Cisco UCS B-Series chassis by using the Auto Install feature. Which component is upgraded during the infrastructure firmware upgrade stage?

A. Cisco IMC

B. Adapter

C. I/O module

D. BIOS

Refer to the exhibit.

An engineer monitors ingress traffic from Host-A and all traffic for VLAN 20 from Host-B. Which configuration must be implemented to monitor and export traffic to Network Analyzer?

A. SW-1(config)# monitor session 5 SW-1(config-monitor)# source interface ethernet 1/2 rx SW-1(config-monitor)# source interface ethernet 1/1 tx SW-1(config-monitor)# source vlan 20 both SW-1(config-monitor)# destination ip 10.10.10.1 SW-1(config-monitor)# no shut

B. SW-1(config)# monitor session 5 type erspan-source SW-1(config-erspan-src)# source interface ethernet 1/2 rx SW-1(config-erspan-src)# source vlan 20 both SW-1(config-erspan-src)# destination ip 10.10.10.1 SW-1(config-erspan-src)# erspan-id 111 SW-1(config-erspan-src)# no shut

C. SW-1(config)# monitor session 5 SW-1(config-monitor)# source interface ethernet 1/2 rx SW-1(config-monitor)# source interface ethernet 1/1 both SW-1(config-monitor)# source vlan 20 both SW-1(config-monitor)# destination interface ethernet 2/1 SW-1(conflg-monitor)# no shut

D. SW-1(config)# monitor session 5 type erspan SW-1(config-erspan-src)# source interface ethernet 1/2 rx SW-1(config-erspan-src)# source interface ethernet 1/1 both SW-1(config-erspan-src)# destination ip 10.10.10.1 SW-1(config-erspan-src)# mtu 1000 SW-1(config-erspan-src)# no shut

The Cisco Nexus 5600 Series Switch experiences occasional packet drops on interface ethernet 1/16. An engineer wants to implement a SPAN session to investigate the issue further. The network analyzer to which the packets must be directed is located on interface 1/3. The analyzer is limited on disk space available for traffic capture, so the Nexus switch should send only the relevant data.

Which two command sets configure the SPAN session that meets these requirements? (Choose two.)

A. Option A

B. Option B

C. Option C

D. Option D

E. Option E

An engineer must configure device aliases for a Cisco MDS 9000 Series Switches-based SAN fabric. The configuration must meet these requirements:

1.

The engineer must be prompted before the changes are committed to the database.

2.

Pending changes must be explicitly displayed on the console.

Which command accomplishes this task?

A. device-alias enhanced

B. device-alias commit

C. device-alias confirm-commit

D. device-alias distribute diffs-only
