2V0-41.19 Online Practice Questions and Answers

Which two commands are used to query the arp-table of a logical switch? (Choose two.)

A. get logical-switch arp-table

B. get logical-switch arp-table

C. get logical-switch arp-table

D. get logical-switch arp-table

E. get logical-switch arp-table

What is the maximum supported ECMP paths in NSX-T 2.4 Data Center?

A. 6

B. 8

C. 9

D. 7

An NSX administrator is migrating vSphere port groups configured in vSphere to N-VDS.

What are two migration options? (Choose two.)

A. Migrate vSphere port groups using the esxcli command line.

B. Migrate vSphere port group through the NSX Manager API Calls.

C. Migrate Networking from the vCenter Server.

D. Migrate from the NSX Manager UI, go to Fabric -> Profile -> Uplink Profiles path.

E. Migrate from the NSX Simplified UI> Click Transport Node > Configure NSX > PNIC Only Migration path.

An NSX administrator has configured a KVM hypervisor as a transport node. Which kemel module on KVM implements a N VDS?

A. dvswitch

B. nsx-vswitch

C. openvswitch

D. etherswitch

A company is planning to implement NSX-T Data Center and will be using load balancing for 50 unique production workloads.

Which is the minimum NSX-T Edge size configuration required to support the production load balancer?

A. Large (8 vCPU 16GB RAM)

B. Medium (4 vCPU 8GB RAM)

C. Extra Large (12 vCPU 24GB RAM)

D. Small (2 vCPU 4GB RAM)

An NSX administrator is planning to deploy a multi-tier routing topology in their NSX-T Data Center environment to provide north-south connectivity for the VMs.

Which routing component must be deployed?

A. Tier-0 Gateway

B. Edge Node

C. Tier-1 Gateway

D. Edge Cluster

Which security feature on Tier-1 Gateways helps limit malicious traffic?

A. Unicast Reverse Path Forwarding (URPF)

B. Centralized Service Port (CSP)

C. Promiscuous Mode

D. Reverse Path Forwarding (RPF)

Refer to the exhibit.

An NSX administrator has disabled VMware Identity Manager (vIDM) integration with NSX Manager. The administrator is no longer able to log in to VMware NSX Manager and receives the error shown in the exhibit.

Which NSX CLI command on the NSX Manager would fix this issue?

A. clear auth-policy vidm disabled

B. clear auth-policy vidm stop

C. clear auth-policy vidm enabled

D. clear auth-policy vidm start

An NSX administrator has been tasked with deploying a NSX Edge Virtual machine through an ISO image.

Which virtual network interface card (vNIC) type must be selected while creating the NSX Edge VM to allow participation in overlay and VLAN transport zones?

A. VMXNET3

B. VMXNET2

C. e1000

D. Flexible

In an enterprise-based single-tier routing topology, which routing component provides east-west routing functionality?

A. Tier-0 Gateway

B. Edge Node

C. Edge Cluster

D. Tier-1 Gateway
